Description
Pioneer TS-D69F 6" x 9" 2-Way Coaxial System
- 26mm Polyester Soft Dome Tweeter with Swivel Capability
- Aramid Fiber Interlaced Injection Molded Polypropylene (IMPP) Cone Construction
- Universal Woofer Basket Design Expands Installation Flexibility for Maximum Bass and Sound Quality
- System Type 2-way Coaxial
- Sound Pressure Level (Sensitivity) 87dB (+- 1.5dB)
- Frequency Range 33 Hz to 42 kHz
- Continuous Power Handling (RMS) 110 Watts
- Maximum Peak Power Handling 330 Watts
- Nominal Impedance 4 ohms
- Diameter 6" x 9"
- Cone Material Aramid Fiber Interlaced Injection Molded Polypropylene (IMPP)
- Center Cap Material Polyethylene Terephthalate (PET)
- Surround Material Butyl Rubber
- Magnet Material Ferrite
- Magnet Weight 15.2 oz
- Type Soft Dome
- Diameter 26mm
- Diaphragm Material Polyester
- Magnet Material Neodymium
- Magnet Weight 6.4 g
- Swivel Type Yes
- Crossover Frequency 3500 Hz
- Warranty: 1 year
MPN: TS-D69F | Category: Speakers
