Proscenium PR-LOC2.4-PRO 2 In/4 Out Active Line Output Converter with Bass Boost and 40V Input

Proscenium PR-LOC2.4-PRO 2 In/4 Out Active Line Output Converter with Bass Boost and 40V Input

This 4-channel Active LOC with Bass Boost has universal applications and enables installers to add aftermarket amplifiers to OEM source units for enhanced sound quality. This advanced technology features incredible input power capabilities, a load selector, clip indicator, enhanced output controls, and noise isolation countermeasures. This supplemental product will directly plug into the PRO series LOC’s and line driver.

Product Highlights:

• Condition: New
• 4-channel: 2 in, 4 out
• Max input level: 40V / 400W @20K Ohm
• Operating voltage: 9V-16V
• Optional PR-RM-1
• Trigger selection: REM / DC / AUDIO
• Remote Output Rating 500mA
• Turn on trigger (DC): 3V-7V
• Output max @13.8V: 9.5V RMS
• Input impedance selection: 20 / 60 / 20k Ohm
• Ground selection: GND / ISO / 200 Ohm
• Independent Front/Rear Gain adjustment: – 28dB to +1dB
• Input sensitivity: 0.5V-20V
• Signal to noise: >110dB @6.4V output
• THD+N (Total Harmonic Distortion): <0.01%
• Frequency response: 20Hz – 20kHz
• Low pass filter: <250Hz (rear channels)
• Bass boost: 0dB + 12dB (rear channels)
