Description
Details:
An authentic 3-way coax capable of reproducing a wide frequency spectrum. The DCX 690.3 uses an oversized magnetic group, TPU (Thermoplastic polyurethane) surround, a 60 mm diameter midrange and a PEI dome tweeter. The result is linearity, wide dispersion and extra-ordinary efficiency not found in traditional coax components. An involving, emotional sound, even at high SPL levels.
Highlights:
- Peak Power Handling (Speakers): 180 Watts
- Frequency Response: 45Hz-21kHz
- Impedance: 4 ohms
- Tweeter Size (in): 0.6
- Sensitivity: 93dB
- RMS: 90 Watts
- Large motor assembly for mobile voice coil control
- Pure copper voice coil, wound on conex former, for maximum lightness
- Water-repellent treated paper cone
- TPU surround, for wide excursion and resonance damping
- 60 mm paper tweeter with ferrite magnet
- Supertweeter with PEI dome, for compactness and energy at high frequencies
- DIN size basket protected by abrasion-proof dust paint
- Tin-plated, high current terminals
- Silver-plated lead wires for maximum reliability and conductivity
- Butyl rubber protective cover, against crashes and abrasions
- Epoxy glue for basket and motor system provides perfect coupling
- Low carbon content plates for maximum magnetic permeability and high heat dissipation
MPN: DCX6903 | Category: Speakers
