JL Audio XDM-Series XDM600/1 Monoblock Class D 600W Marine Subwoofer Amplifier

JL Audio XDM-Series XDM600/1 Monoblock Class D 600W Marine Subwoofer Amplifier

This potent monoblock amplifier employs JL Audio's high-speed NexD switching design to achieve unprecedented efficiency and amazing power output from a very compact chassis. The XDM600/1 generates serious subwoofer power, delivering a full 600 W of continuous power into a 2-ohm load (14.4V, 1% THD).

Designed for car or boat installations, the XDM600/1 is built with marine-grade materials and features an exclusive, dual-mode input filter for noise-free performance in boats or cars. Automatic turn-on capability is also onboard for easy factory system upgrades.

Product Highlights:

• Class D 2 ohms Stable Monoblock Marine Subwoofer Amplifier
• 4 ohms: 400 watts x 1 channel
• 2 ohms: 600 watts x 1 channel
• Total RMS power output: 600 watts
• Pulse Width Modulated MOSFET power supply
• LED Power/Protect Light
• Wired remote bass level control included
• Soft start turn-on
• 3-way protection circuitry (thermal, overload, and speaker short protection)
• Frequency Response: 7 - 500 Hz
• Total Harmonic Distortion (THD): <1.0%
• Signal Noise Ratio: 87 dB
• Variable low-pass filter: 50 - 500 Hz
• Fuse Rating: 50
• 4 AWG gauge power and ground wiring are recommended for installation.
