JL Audio VX700/5i 700W Max 5-Channel Class-D Amplifier with Built-In DSP

Sometimes, beauty's only skin deep and other times, it's what's on the inside that counts. But when you find something gorgeous inside and out, you never pass it up. JL Audio's brand new VXi amplifiers are designed not with a balance of beauty and function, but an abundance of both. JL Audio's VXi Amplifiers do just that.

The VX1000/5i 5-Channel amplifier has a built in Digital Signal Processor (DSP). Instead of concealing the controls behind a metal plate, all the tuning is right at your fingertips. Just connect with the free TüN app.

Once your installation is finished, you can tune from anywhere, and you can change your settings without getting out the tool kit. Adjust the parametric EQs on each channel, the gain and more through a phone, tablet or computer.

But who says looks don't matter? JL Audio placed all the connections on the VXi amps on one side, cleaning up every installation. The chassis hides all the mounting hardware. The logo badge rotates in 90-degree increments, depending on how you need to mount it, and you can change the LED backlight color to match your system. What are you waiting for? Get your VX1000/5i now and hit Add to Cart!

General Features:

• JL Audio VXi Series VX700/5i
• Class-D Full Range 4-Ohm Stable 5-Channel Amplifier
• CEA-2006 Compliant Amplifier
• Pulse Width Modulated MOSFET power supply
• Wired remote bass level control included
• LED power (green) and protect (red) indicators
• Soft start turn-on
• 4/3/2 or Mono channel operation
• Speaker-level (high-level) inputs
• Preamp RCA outputs to daisy chain multiple amps
• 3-way protection circuitry (thermal, overload, and speaker short protection)
• Dual speaker terminals simplify the hookup of multiple speakers
• Heavy duty aluminum alloy heat-sink

RMS Power Rating:

• 4 ohms: 75 watts x 4 chan.
• 2 ohms: 100 watts x 4 chan.
• Bridged, 4 ohms: 200 watts x 2 chan.

Damping Factor:

• 4 Ohms: >150/50 Hz
• 2 Ohms: >50/50 Hz

Input sensitivity:

• High level: 200mV-16V
• Frequency Response: 12 Hz- 24 kHz
• Total Harmonic Distortion (THD): 1%
• Signal to Noise Ratio: 99 dB

Unmatched built-in DSP functionality:

• Premium, triple-core AKM DSP with an optimized configuration
• Hi-Res audio processing at 24 bit/96 kHz
• High-performance AKM A/D and D/A converters
• 10 Bands of parametric EQ per channel, including pre-outs
• Shelving EQ option for Bands 1 and 10
• High and Low-Pass Filters for each channel, with selectable

Alignments and Slopes:

• Linkwitz-Riley: 12, 24, 48 dB/octave
• Butterworth: 6, 12, 18, 24, 36, 48 dB/octave
• Signal Delay in 0.01 millisecond steps
• All-Pass Filter (Phase EQ), with variable "Q" and corner frequency
• Polarity Reversal (0 or 180 deg.)
• Output Level Trim in 0.1 dB steps
• Fuse Rating: 60 A x 1
• 4 gauge power and ground wiring is recommended for installation.
• Dimensions: 6.62"W 9.81 "L x2.12 "H

Authorized Internet Dealer

• 1-year Manufacturer's Warranty
