Pioneer GM-D8604 Class D 4 CH Bridgeable Amplifier with Bass Boost Remote

Pioneer GM-D8604 4-channel car amplifier

Pioneer's new extra-efficient Class-D digital amplifiers mark a dramatic improvement in power output capability, yet are 50% smaller than the current GM-Series Class-AB amplifiers. That makes them more versatile in terms of installation as well as performance.

Product Highlights:

• 4-channel car amplifier
• 100 watts RMS x 4 at 4 ohms (150 watts RMS x 4 at 2 ohms)
• 125 watts RMS x 4 at 1 ohm
• 300 watts RMS x 2 bridged at 4 ohms (250 watts RMS x 2 bridged at 2 ohms)
• CEA-2006 compliant
• Full-range Class D amp technology
• Variable high- and low-pass filters (40-500 Hz, 12 dB per octave)
• Preamp inputs and outputs
• Speaker-level inputs via supplied RCA-type adapters
• Fuse rating: 30A x 2
• 4-gauge power and ground leads recommended — wiring and hardware not included with amplifier
• 11"W x 2-3/8"H x 7-7/8"D
• Warranty: 1 year

What's in the Box:

• 4-Channel amplifier
• Two 30 amp ATO fuses (installed)
• Two 8" Speaker-level input adapters
• 3mm Allen wrench
• Four 5/8" Self-tapping screws
